This advanced aluminium window and door system delivers outstanding thermal performance, security and flexibility. Suitable for both residential and commercial applications, it provides a robust solution for projects requiring long-term durability and exceptional performance.
| Specification | Functional | Renaissance | Hidden Vent |
|---|---|---|---|
| Min. Visible Width (Inward Window) – Frame | 51 mm | 51 mm | 76 mm |
| Min. Visible Width (Inward Window) – Vent | 33 mm | 33 mm | Not Visible |
| Min. Visible Width (Outward Window) – Frame | 17.5 mm | – | – |
| Min. Visible Width (Outward Window) – Vent | 76 mm | – | – |
| Min. Visible Width (Inward Flush Door) – Frame | 68 mm | – | – |
| Min. Visible Width (Inward Flush Door) – Vent | 76 mm | – | – |
| Min. Visible Width (Outward Flush Door) – Frame | 42 mm | – | – |
| Min. Visible Width (Outward Flush Door) – Vent | 102 mm | – | – |
| Min. Visible Width T-Profile | 76 mm | 76 mm | 126 mm |
| Overall System Depth – Frame | 68 mm | 77 mm | 68 mm |
| Overall System Depth – Vent | 77 mm | 86 mm | 72.5 mm |
| Rebate Height | 25 mm | 25 mm | 18.5 mm |
| Glass Thickness | Up to 53 mm | Up to 53 mm | Up to 48 mm |
| Glazing Method | Dry glazing with EPDM or neutral silicones | ||
| Thermal Insulation | 32 mm omega and/or hollow chamber-shaped fibreglass reinforced polyamide strips | ||
| High Insulation (HI) | Available | Available | Not Available |
| High Insulation Plus (HI+) | Available | Not Available | Not Available |
